CALL H&k PUMP FOR SALES AND SERVICE.  WE REBUILD ALL CURTIS COMPRESSOR PUMPS.  IN ADDITION, WE TYPICALLY KEEP MOST OF THE PARTS IN STOCK EITHER INSIDE OUR WAREHOUSE OR AT THE CORPORATE OFFICE.  WE DROP SHIP DIRECTLY TO YOU.

214-428-2868





ITEM DESCRIPTION QTY PART NUMBER
AIR STRAINER
1 Air Strainer Assembly 2 2601540560
2 Air Strainer Element (Not Shown) 2 2601540410
VALVE & UNLOADERS
3 Outlet Valve Push C over Bolt; M8 x L25, Gr 8.8 16 2102010189
4 Outlet Valve Push Cover (1st) 2 2601026250
5 Viton O-ring G 55 (Outlet Valve-1st) 2
Outlet Valve Assembly (1st) 2
Nut; M10 (Outlet Valve-1st) 4
Outlet Valve Receiver (1st) 2
6 Outlet Valve Spring (1st) 2 2601320190
Inlet/Outlet Valve Plate (1st) 4
Outlet Valve Seat (1st) 2
Outlet Valve Bolt; M10 x L50, Gr 8.8 (1st) 2
7 Inlet & Outlet Valve Gasket (1st) 4
8 Inlet Valve Push Cover (1st) 2 2601026210
9 O-ring G 55 (Inlet Valve-1st) 2
10 Viton O-ring P 21 (Unloader-1st) 2
11 Unloader Piston (1st) 2 2601026230
Inlet Valve Assembly-1st 2
Locknut; M10 (Inlet Valve-1st) 2
Inlet Valve Unloader Fork (1st) 2
Inlet Valve Unloader Fork Guide (1st) 2
12 2601310880
Unloader Spring (1st) 2
Inlet Valve Seat (1st) 2
Inlet Valve Spring (1st) 2
Inlet Valve Receiver (1st) 2
13 Outlet Valve Push Cover (2nd) 1 2601024510
14 Viton O-ring G 40 (Inlet/Outlet Valve-2nd) 2
Outlet Valve Assembly (2nd) 1
Nut; M8 (Outlet Valve-2nd) 2
Outlet Valve Receiver (2nd) 1
15 Inlet/Outlet Valve Plate (2nd) 2 2601320070
Outlet Valve Spring (2nd) 1
Outlet Valve Seat (2nd) 1
Outlet Valve Bolt (2nd) 1
16 Inlet & Outlet Valve Gasket (2nd) 2
17 Inlet Valve Push Cover (2nd) 1 2601024420
18 Unloader Piston (2nd) 1 2601024450
19 Viton O-ring P 20 (Unloader-2nd) 1
Inlet Valve Assembly (2nd) 1
Inlet Valve Unloader Fork (2nd) 1
Unloader Spring (2nd) 1
20 2601311230
Inlet Valve Unloader Fork Guide (2nd) 1
Inlet Valve Seat (2nd) 1
Inlet Valve Spring (2nd) 1
Inlet Valve Receiver (2nd) 1
21 Cylinder Head Bolt (1st); M10 x L80, Gr 8.8 12 2102010331
22 Cylinder Head (1st) 2 2601027070
23 Head - Cylinder Gasket (1st) 2
24 Cylinder Head Bolt (1st); M10 x L25, Gr 8.8 8 2102010265
25 Cylinder Head (2nd) 1 2601030190
26 Head - Cylinder Gasket (2nd) 1
27 Compression Ring (1st) 4
28 Oil Control Ring (1st) 4
29 Piston Pin Snap Ring (1st) 6 2601026880
30 Piston Pin (1st) 2 2601026990
31 Piston (1st) 2 2601026820
32 Cylinder (1st) 2 2601027080
33 Cylinder Nut (1st); M10 12 2102030065
34 Cylinder Bolt Copper Washer (1st); M10 12 2102040140
35 Cylinder Bolt (1st); M10 x L40, Gr 8.8 8 2601024620
36 Cylinder - Case Gasket 3
37 Compression Ring (2nd) 3
38 Oil Control Ring (2nd) 2
39 Piston (2nd) 1 2601030090
40 Piston Pin (2nd) 1 2601030120
41 Cylinder (2nd) 1 2601030200
42 Cylinder Bolt (1st); M10 x L43, Gr 8.8 4 2601030010
CONNECTING ROD
43 Connecting Rod Assembly(1st) 2
44 Connecting Rod Crank Pin Metal (1st) 6
45 Oil Splash Dipper 2 2601030280
46 Connecting Rod Assembly (2nd) 1
47 Oil Splash Dipper 1 2601030290
CRANKCASE & CRANKSHAFT
48 Breather Assembly (Rubber) 1 2601026671
49 Rear Bearing Cover Bolt Copper Washer; M10 10
50 Rear Bearing Cover 1 2601029750
51 Rear Bearing Cover Gasket 1
52 Oil Baffle 1 2601029870
53 Front & Rear Bearing 2
54 Crankshaft Counterweight Bolt; M12 x L72, Gr 8.8 2 2601026430
55 Crankshaft Counterweight 2 2601029620
56 Crankshaft 1 2601030040
57 V-Pulley Pin 1 2601029650
58 Oil Level Glass Bolt; M5 x L20, Gr 8.8 4 FVH1470
59 Oil Level Glass Push Cover 1 2601026780
60 Oil Level Glass Assembly 1 2601026740
61 Oil Level Glass Gasket 1 2601026770
62 Crankcase Oil Plug (1/2" PT) 1 2102020061
63 Crankcase 1 2601029910
64 Oil Fill Cap 1 2601024910
65 O-ring (Oil Fill Cap) 1 2111010013
66 Front Bearing Cover Gasket 1
67 Front Bearing Cover 1 2601029711
68 Front Oil Seal 1
69 Cylinder Head Bolt (1st); M10 x L30, Gr 8.8 6 2102010276
70 Compressor Pulley 1 2601234581
71 Compressor Fan 1 2601232610
72 Compressor Fan Spring Washer, M8 6 2102040137
73 Compressor Fan Bolt; M8 x L30, Gr 8.8 6 2102010197
74 Compressor Pulley Thrust Washer 1 2601232980
75 Compressor Pulley Spring washer; M12 1 2102040143
76 Compressor Pulley Bolt; M12 x L40, Gr 8.8 1 2102010405
DISCHARGE PIPING
77 Outlet Piping Joint 1 2601490972
77A Outlet Piping Joint Check valve 1 2104110056
78 Outlet Piping Joint 2 2601490971
79 Discharge Piping Assembly - Short 1 2601491971
80 Outlet Piping Joint 1 2601492011
81 Discharge Piping Assembly - Long 1 2601492030
SERVICE KITS SYMBOL
FSK-E71GK
FSK-E71VK
FSK-E71RK
FSK-E71LERK




AIR COMPRESSOR SERVICE

E71 COMPRESSOR PARTS

CURTIS 10HP COMPRESSOR PARTS

AIR COMPRESSOR PUMP REPAIR

AIR COMPRESSOR MOTOR REPAIR

AIR COMPRESSOR DRYER

AIR COMPRESSOR DRYER SERVICE


214-428-2868

AIR COMPRESSOR PARTS

AIR COMPRESSOR OIL





E71 COMPRESSOR PARTS



10HP SIMPLEX COMPRESSOR


Capacity and power: ISO-1217(1996 annex #C)
Normal working pressure - psi 175
Capacity at normal working press - cfm 34.2
Basic Pump
Model E71
Stage 2
Lubrication type Splash Lubrication
Valve type Disc Valve - Stainless Steel
RPM (min - max) - rpm 500 - 1050
Outfit RPM 927
BHP - HP 10.78
Bore (LP/HP) - inch (2) 3.93” - 3.15”
Stroke - inch 2.76”
Inlet size Rc1 BSPT
Discharge size 7/8”OD
Sheave OD 11.81”
Sheave PD 11.46”
Number of belts 3
Belt section B
Low oil sight glass Sight Glass
Oil quantity 5 Pints
Unloaders and Method Pressure Switch Unloader standard, Suction Head option
Noise level - dB(A) 86
Motor 3-200V 3-230V 3-460 3-575V
Enclosure IP23 IP23 IP23 IP23
Insulation Class F F F F
Efficiency - % 89.5 91.7 91.7 91.7
Nominal rated power - HP 10 10 10 10
Speed of rotation - rpm 1765 1770 1770 1770
FLA 30.8 25.0 12.5 10.0
Service factor 1.15 1.15 1.15 1.15
Locked rotor current - A 218 168 84 67
Power Factor 78 82 82 82
Installation condition
Allowed ambient temperature min - max - °F 32-104
Compressor dimensions
Air Receiver Type Vertical Vertical UP Horizontal Horizontal UP
Air receiver size (Gal) 120 120 120 120
Compressor outlet 3/4" NPT 3/4" NPT 3/4” NPT 3/4” NPT
Length - inch 45 45 74 74
Width - inch 34 34 26 37
Height - inch 80 80 53 54
Weight - Lbs. 940 1026 940 1026
Air Cooled Aftercooler (Option)
Availability Yes
Air cooled aftercooler CTD - °F 18












10HP DUPLEX COMPRESSOR


Capacity and power: ISO-1217(1996 annex #C)
Normal working pressure - psi 175
Capacity at normal working press - cfm 68.4
Basic Pump
Model E71
Stage 2
Lubrication type Splash Lubrication
Valve type Disc Valve - Stainless Steel
RPM (min - max) - rpm 500 - 1050
Outfit RPM 927
BHP - HP 10.78
Bore (LP/HP) - inch (2) 3.93” - 3.15”
Stroke - inch 2.76”
Inlet size Rc1 BSPT
Discharge size 7/8”OD
Sheave OD 11.81”
Sheave PD 11.46”
Number of belts 3
Belt section B
Low oil sight glass Sight Glass
Oil quantity 5 Pints
Unloaders and Method Pressure Switch Unloader standard, Suction Head option
Noise level - dB(A) 86
Motor 3-200V 3-230V 3-460 3-575V
Enclosure IP23 IP23 IP23 IP23
Insulation Class F F F F
Efficiency - % 89.5 91.7 91.7 91.7
Nominal rated power - HP 10 10 10 10
Speed of rotation - rpm 1765 1770 1770 1770
FLA 30.8 25.0 12.5 10.0
Service factor 1.15 1.15 1.15 1.15
Locked rotor current - A 218 168 84 67
Power Factor 78 82 82 82
Installation condition
Allowed ambient temperature min - max - °F 32-104
Compressor dimensions
Air Receiver Type Horizontal Horizontal UP
Air receiver size (Gal) 120 120
Compressor outlet 3/4” NPT 3/4” NPT
Length - inch 90 90
Width - inch 30 32
Height - inch 53 53
Weight - Lbs. 1225 1311
Air Cooled Aftercooler (Option)
Availability Yes
Air cooled aftercooler CTD - °F 18




CURTIS MASTER LINE SERIES AIR COMPRESSORS:






10HP AIR COMPRESSOR



AIR COMPRESSOR SERVICE
E71 COMPRESSOR PARTS
CURTIS D97 PUMP
CURTIS 10HP COMPRESSOR PARTS
AIR COMPRESSOR PUMP REPAIR
AIR COMPRESSOR MOTOR REPAIR
AIR COMPRESSOR DRYER
AIR COMPRESSOR DRYER SERVICE
214-428-2868
AIR COMPRESSOR PARTS
AIR COMPRESSOR OIL






10HP AIR COMPRESSOR







Model HP Part No. Pump Voltage CFM
ML5 5 FML05D96BXS-A2L1XX D96 1/60/230V 19.1
ML5 5 FML05D96BXS-A9L1XX D96 3/60/200-208V 19.1
ML5 5 FML05D96BXS-A3L1XX D96 3/60/230V 19.1
ML5 5 FML05D96BXS-A4L1XX D96 3/60/460V 19.1
ML7.5 7.5 FML07C79BXS-A2L1XX C79 1/60/230V 28.7
ML7.5 7.5 FML07C79BXS-A9L1XX C79 3/60/200-208V 28.7
ML7.5 7.5 FML07C79BXS-A3L1XX C79 3/60/230V 28.7
ML7.5 7.5 FML07C79BXS-A4L1XX C79 3/60/460V 28.7
ML10 10 FML10D97BXS-A9L1XX D97 3/60/200-208V 39.8
ML10 10 FML10D97BXS-A3L1XX D97 3/60/230V 39.8
ML10 10 FML10D97BXS-A4L1XX D97 3/60/460V 39.8
ML15 15 FML15D97BXS-A9L1XX D97 3/60/200-208V 49.5
ML15 15 FML15D97BXS-A3L1XX D97 3/60/230V 49.5
ML15 15 FML15D97BXS-A4L1XX D97 3/60/460V 49.5
ML15+ 15 FML15C89BXS-A9L1XX C89 3/60/200-208V 55.8
ML15+ 15 FML15C89BXS-A3L1XX C89 3/60/230V 55.8
ML15+ 15 FML15C89BXS-A4L1XX C89 3/60/460V 55.8
ML20+ 20 FML20C98BXS-A9L1XX C98 3/60/200-208V 79.3
ML20+ 20 FML20C98BXS-A3L1XX C98 3/60/230V 79.3
ML20+ 20 FML20C98BXS-A4L1XX C98 3/60/460V 79.3
ML25 25 FML25C98BXS-A9L1XX C98 3/60/200-208V 82.4
ML25 25 FML25C98BXS-A3L1XX C98 3/60/230V 82.4
ML25 25 FML25C98BXS-A4L1XX C98 3/60/460V 82.4
ML30 30 FML30C98BXS-A9L1XX C98 3/60/200-208V 102.2
ML30 30 FML30C98BXS-A3L1XX C98 3/60/230V 102.2
ML30 30 FML30C98BXS-A4L1XX C98 3/60/460V 102.2












LPSV SERVICE KIT
KIT NUMBER PARTS DESCRIPTION
FCMA607-P VALVE SUCTION ASSY
FCDA1286 VALVE GASKET OLD #VB916
FVH08KN SCREW HEX HD CUP PT 3/8-16 X 1-3/4 BL OX
FCA29948 SPRING UNLOADER FORK
FCBB928 FORK UNLOADER ASSY
FSK-D97LPSV
FVH1232 WASHER 9/16 X 25/64 X 0.051 ALUMINUM
FCM656 GASKET VALVE HIGH PRESS ORDER W/ CM657
FRK2063 NUT STUD REPLACES RK29E
FVH12PM1 SCREW HEX HD 1/2-13UNC X 1-1/2 GR5 ZN PL
FCBA959 CYLINDER ASSY UNLOADER LP SUCTION VALVE





10HP AIR COMPRESSOR




LPDV SERVICE KIT
KIT NUMBER PARTS DESCRIPTION
FCDA1208-P VALVE DISCHARGE ASSY
FCM656 GASKET VALVE HIGH PRESS ORDER W/ CM657
FVH12PM1 SCREW HEX HD 1/2-13UNC X 1-1/2 GR5 ZN PL
FSK-D97LPDV FVH1232 WASHER 9/16 X 25/64 X 0.051 ALUMINUM
FVH08KP SCREW SOCKET HEAD CUP PT 3/8-16 X2 BL OX
FRK2063 NUT STUD REPLACES RK29E
FCDA1286 VALVE GASKET OLD #VB916







HPSV SERVICE KIT
KIT NUMBER PARTS DESCRIPTION
FCDA1204 D97 HPSV KIT
FVB913 GASKET VALVE COPPER
FCDB1216 GASKET HIGH PRESS SUCTION VALVE ALUMINUM
FSK-D97HPSV
2601314010 CAP SUCTION VALVE
FCBA980 PH, D97 H.P.S.V. UNLOADER SUB-ASSY
FCBB926 CYLINDER ASSY UNLOADER HP SUCTION VALVE
HPDV SERVICE KIT
KIT NUMBER PARTS DESCRIPTION
FCDA1205 D97 HPDV KIT
2601321070 PLUG
FVH08KR SCREW HEX HEAD CUP PT 3/8 X 2-1/2 ZN PL
FSK-D97HPDV FVH1232 WASHER 9/16 X 25/64 X 0.051 ALUMINUM
FRK2063 NUT STUD REPLACES RK29E
FVB910 GASKET COPPER 1-15/16 X 1-11/16 X 1/16
FCDA1282 GASKET HIGH PRESSURE VALVE






10HP AIR COMPRESSOR






KIT NUMBER PARTS DESCRIPTION
FCDA1225 GASKET INTERCOOLER MANIFOLD
FCD12082 GASKET CYLINDER HEAD
FCD1239A GASKET SIDE DOOD D97
FCJ4121 GASKET CRANKCASE D97
FCJ4122 GASKET END PLATE D97
FCJ4124 GASKET SMALL END PLATE D97
FCD1290 SHIMS SET
FCM656 GASKET VALVE HIGH PRESS ORDER W/ CM657
FVB403 O-RING 1/8 X 1 ID NOM  FLUOROCARBON BLCK
FSK-D97AGK FVB407 O-RING (PACKING)
FVH1223 WASHER 17/32 X 45/64 X 0.05 COPPER
FVH1232 WASHER 9/16 X 25/64 X 0.051 ALUMINUM
FVB913 GASKET VALVE COPPER
FCDA1282 GASKET HIGH PRESSURE VALVE
FCDA1286 VALVE GASKET OLD #VB916
FVB910 GASKET COPPER 1-15/16 X 1-11/16 X 1/16
FCDB1216 GASKET HIGH PRESS SUCTION VALVE ALUMINUM
FCM665 GASKET BREATHER COVER ALL ML
FCA2312A GASKET/FLANGE COVER PLATE - REPL CA2312
PISTON RING SERVICE KIT
KIT NUMBER PARTS DESCRIPTION
FSK-D97RNG FCDA1258 RING LOW PRESSURE SET D96 OLD #CM791
FCQ868 RING SET HP D97 C89 STD SZ (OLD#CQ869)
1000 HR SERVICE KIT
KIT NUMBER PARTS DESCRIPTION
FSK-D9710SK FVA1121 FILTER ELEMENT 1-1/2
FSC-1000QT OIL FSC-1000 1 QUART RECIP OIL
REBUILD SERVICE KIT
KIT NUMBER PARTS DESCRIPTION
FCO1920 KIT LOWER END REBUILD D9727A-D9745
FVA1121 FILTER ELEMENT 1-1/2
FSK-D97LPSV KIT, VALVE REPLACEMENT D97 L.P.S.V.
FSK-D97RK
FSK-D97LPDV KIT, VALVE REPLACEMENT D97 L.P.D.V.
FSK-D97HPSV KIT, VALVE REPLACEMENT D97 H.P.S.V.
FSK-D97HPDV KIT, VALVE REPLACEMENT D97 H.P.D.V.
LOWER END REBUILD SERVICE KIT
KIT NUMBER PARTS DESCRIPTION
FCDA1244 CONNECTING ROD BEARING SET
FCDA1259 BUSHING CONNECTING ROD HIGH + LOW PRESS
FCDA1258 RING LOW PRESSURE SET D96 OLD #CM791
FCO1920 FCQ868 RING SET HP D97 C89 STD SZ (OLD#CQ869)
FCD1290 SHIMS SET
FSK-D97AGK SERVICE D97 GASKET KIT
FVB301 OIL SEAL 1-7/8ID X 2-7/8 OD X 5/15 THICK






10HP AIR COMPRESSOR







PARTS LIST - L.P. SUCTION - UNLOADER CYLINDER ASSEMBLY
DESCRIPTION PART NUMBER
LPSV UNLOADER PISTON FCBA960
O-RING FVB407
CYLINDER-UNLOADER FCBA961
LOCKNUT FCB6138
CAP-UNLOADER CYLINDER FCBA924




PARTS LIST - H.P. SUCTION VALVE - UNLOADER CYLINDER ASSEMBLY
DESCRIPTION PART NUMBER
O-RING FVB407
PISTON-UNLOADER FCBA972
SPRING COMPRESSION-BYPASS UNLOADER FCBA976
CYLINDER-UNLOADER FCBB925
LOCKNUT FCB6138
CAP-UNLOADER CYLINDER FCBA924






PARTS LIST - H.P. SUCTION VALVE SECOND SUB- ASSEMBLY
DESCRIPTION PART NUMBER
PIN-UNLOADER-HP./CADMIUM  PLATED FCBB929
WASHER-UNLOADER PIN FCB982
SPRING-UNLOADER FCB6027
COTTER- 1/16 X 1/2 FVH23BD
PLUG-HIGH PRESSURE SUCTION VALVE 2601313990
FORK, UNLOADER FCB981
ROLL PIN 3/32 X 1/4 FVH25CB







PARTS LIST - H.P. DISCHARGE VALVE - SECOND SUB-ASSEMBLY
PART NUMBER
PLUG 2601321070
SET SCREW-HEX. HEAD-FLAT POINT 3/8 X 2 1/2 FVH08KR
WASHER-ALUMINUM 9/16 X 25/64 X 0.051 FVH1232
NUT-STUD FRK2063





AIR COMPRESSOR SERVICE

E71 COMPRESSOR PARTS

CURTIS D97 PUMP

CURTIS 10HP COMPRESSOR PARTS

AIR COMPRESSOR PUMP REPAIR

AIR COMPRESSOR MOTOR REPAIR

AIR COMPRESSOR DRYER

AIR COMPRESSOR DRYER SERVICE


214-428-2868

AIR COMPRESSOR PARTS

AIR COMPRESSOR OIL















PARTS LIST - CILINDER HEAD
ITEM NO DESCRIPTION AMOUNT PART NUMBER NOTES
1 CYLINDER HEAD 1 2601040050
2 LP VALVE GASKET 2 FCDA1286
3 L.P. SUCTION ASSEMBLY 1 FCMA607-P *IN KIT FSK-D97LPSV
4 SPRING 0.08 DIA X 1 3/8 X 1"OD 1 FCA29948
5 UNLOADER FORK ASSEMBLY 1 FCBB928
6 SPACER 2 2601313900
7 GASKET-VALVE PLATE-H.P. 2 FCM656
8 HP SUCTION VALVE COVER PLATE 1 2601039600
9 HHCS 1/2-13UNC X 1 .5 6 FVH12PM1
10 SCREW SET HEX CUP PT 3/8 X 1 3/4"LG 3 FVH08KN
11 WASHER ALUMINUM 9/16 6 FVH1232
12 NUT-STUD 6 FRK2063
13 L.P. SUCTION ASSEMBLY 2 1 -
14 CAP-UNLOADER CYLINDER 1 FCBA924 INCL. WITH ITEM #13
15 L.P. VALVE DISCHARGE 1 FCDA1208-P *IN KIT FSK-D97LPDV
16 HP DISCHARGE VALVE COVER PLATE 1 2601039630
17 SCREW SOCKET HEAD CUP PT 3/8-16 X2 3 FVH08KP
18 HP VALVE GASKET 1 FCDA1282
19 H.P. DISCHARGE VALVE FIRST ASSEMBLY 1 -
20 GASKET-COPPER 1 15/16 X 1 11/16 X 1/16 1 FVB910
21 H.P. DISCHARGE VALVE SECOND ASSY 1 FCDA1205 *IN KIT FSK-D97HPDV
22 GASKET-COPPER-VALVE 1 FVB913
23 RETAINER 1 FCD1222
24 SPRING 1 FCDA1254
*IN KIT FSK-D97HPSV
25 VALVE DISC HP. 1 FCD1230
26 SEAT 1 FCD1223
27 H.P. SUCTION SECOND ASSEMBLY 1 -
GASKET-ALUMINUM H.P.S.V. 1 FCDB1216
CAP-SUCTION VALVE 1 2601314010
H.P. SUCTION FIRST ASSEMBLY 1 -
TEE COMP RUN 1/8 NPT X 1/4 OD X 1/4 OD 1 FVA729
UNLOADER TUBE 1 FCBA995
COMP MALE ELBOW90 1/4NPT X 1/4 OD BRASS 1 FVA15BCE
NIPPLE- 1 1/4 X 4 SEAMLESS 1 FPTN0714AB
MANIFOLD FLANGE 1 2601494260






AIR COMPRESSOR SERVICE





PARTS LIST - L.P. PISTON ASSEMBLY
DESCRIPTION AMOUNT PART NUMBER
CONNECTING ROD 1 FCDB1333
BEARING-NEEDLE-ROLLER- 2 FVD841
PISTON, L.P. 1 FCDB1368
PISTON PIN, L.P. FOR D97A ONLY 1 FCDB1361
PIN-SELF LOC 1/4 X 11/16 1 FVH1312
SET, CONN ROD BEARING 1 FCDA1244
HHCS 3/8-24UNF X 2 3/4 2 *FVH12JS
LOCKWASHER 3/8" ZINC PLATED 2 FVH35K1
NUT-HEX 3/8-24 2 *FVH15J
RAIL- 6.25 X .024 2 FCAD25310B
EXPANDER-OIL RING 1 FCAD25310A
RING-6.25 X 1/8 REVERSE TWIST 2 FCAD25510
RING-COMPRESSION-BARREL 1 FCAD25610
*NOTE: ITEMS 7, AND 9 INCLUDED WITH ITEM #1











CALL H&k PUMP FOR SALES AND SERVICE.  WE REBUILD ALL CURTIS COMPRESSOR PUMPS.  IN ADDITION, WE TYPICALLY KEEP MOST OF THE PARTS IN STOCK EITHER INSIDE OUR WAREHOUSE OR AT THE CORPORATE OFFICE.  WE DROP SHIP DIRECTLY TO YOU.

214-428-2868





No comments:
