AIR COMPRESSOR BELTS






Here is the rule of thumb for an air compressor
A belt +2 inches
B belt - 3 inches





WWW.HKAIRCOMPRESSORS.COM
WWW.HKAIRCOMPRESSORS.COM
DALLAS, TEXAS
214-428-2868






BELT NUMBER BELT LENGTH
3V1000 100 0.38 10
3V1060 106 0.38 10
3V1120 112 0.38 10
3V1180 118 0.38 10
3V1250 125 0.38 10
3V1320 132 0.38 10
3V1400 140 0.38 10
3V250 25 0.38 10
3V265 26.5 0.38 10
3V280 28 0.38 10
3V300 30 0.38 10
3V315 31.5 0.38 10
3V335 33.5 0.38 10
3V355 35.5 0.38 10
3V375 37.5 0.38 10
3V400 40 0.38 10
3V420 42
3V425 42.5 0.38 10
3V450 45 0.38 10
3V475 47.5 0.38 10
3V500 50 0.38 10
3V530 53 0.38 10
3V560 56 0.38 10
3V590 59
3V600 60 0.38 10
3V630 63 0.38 10
3V650 65 0.38 10
3V670 67 0.38 10
3V710 71 0.38 10
3V730 73 0.38 10
3V750 75 0.38 10
3V800 80 0.38 10
3V810 81 0.38 10
3V830 83 0.38 10
3V850 85 0.38 10
3V900 90 0.38 10
3V950 95 0.38 10
A100 102 0.5 13
A101 103 0.5 13
A102 104 0.5 13
A103 105 0.5 13
A104 106 0.5 13
A105 107 0.5 13
A106 108 0.5 13
A107 109 0.5 13
A108 110 0.5 13
A110 112 0.5 13
A112 114 0.5 13
A113 115 0.5 13
A114 116 0.5 13
A115 117 0.5 13
A116 118 0.5 13
A117 119 0.5 13
A118 120 0.5 13
A120 122 0.5 13
A124 126 0.5 13
A125 127 0.5 13
A127 129 0.5 13
A128 130 0.5 13
A130 132 0.5 13
A132 134 0.5 13
A133 135 0.5 13
A134 136 0.5 13
A136 138 0.5 13
A137 139 0.5 13
A140 142 0.5 13
A144 146 0.5 13
A148 150 0.5 13
A152 154 0.5 13
A156 158 0.5 13
A157 159 0.5 13
A158 160 0.5 13
A162 164 0.5 13
A167 169 0.5 13
A173 175 0.5 13
A180 182 0.5 13
A187 189 0.5 13
A197 199 0.5 13
A20 22 0.5 13
A200 202 0.5 13
A21 23 0.5 13
A22 24 0.5 13
A23 25 0.5 13
A24 26 0.5 13
A25 27 0.5 13
A26 28 0.5 13
A27 29 0.5 13
A28 30 0.5 13
A29 31 0.5 13
A29.8 31.8 0.5 13
A30 32 0.5 13
A31 33 0.5 13
A32 34 0.5 13
A33 35 0.5 13
A34 36 0.5 13
A35 37 0.5 13
A36 38 0.5 13
A37 39 0.5 13
A38 40 0.5 13
A39 41 0.5 13
A40 42 0.5 13
A41 43 0.5 13
A42 44 0.5 13
A43 45 0.5 13
A44 46 0.5 13
A45 47 0.5 13
A46 48 0.5 13
A47 49 0.5 13
A48 50 0.5 13
A49 51 0.5 13
A50 52 0.5 13
A51 53 0.5 13
A52 54 0.5 13
A53 55 0.5 13
A54 56 0.5 13
A55 57 0.5 13
A56 58 0.5 13
A57 59 0.5 13
A58 60 0.5 13
A59 61 0.5 13
A60 62 0.5 13
A61 63 0.5 13
A62 64 0.5 13
A63 65 0.5 13
A64 66 0.5 13
A65 67 0.5 13
A66 68 0.5 13
A67 69 0.5 13
A68 70 0.5 13
A69 71 0.5 13
A70 72 0.5 13
A71 73 0.5 13
A72 74 0.5 13
A73 75 0.5 13
A74 76 0.5 13
A75 77 0.5 13
A76 78 0.5 13
A77 79 0.5 13
A78 80 0.5 13
A79 81 0.5 13
A80 82 0.5 13
A81 83 0.5 13
A82 84 0.5 13
A83 85 0.5 13
A84 86 0.5 13
A85 87 0.5 13
A86 88 0.5 13
A87 89 0.5 13
A88 90 0.5 13
A89 91 0.5 13
A90 92 0.5 13
A91 93 0.5 13
A92 94 0.5 13
A93 95 0.5 13
A94 96 0.5 13
A95 97 0.5 13
A96 98 0.5 13
A97 99 0.5 13
A98 100 0.5 13
A99 101 0.5 13
AX100 102 0.5 13
AX103 105 0.5 13
AX105 107 0.5 13
AX110 112 0.5 13
AX112 114 0.5 13
AX120 122 0.5 13
AX128 130 0.5 13
AX144 146 0.5 13
AX173 175 0.5 13
AX21 23 0.5 13
AX22 24 0.5 13
AX23 25 0.5 13
AX24 26 0.5 13
AX25 27 0.5 13
AX26 28 0.5 13
AX27 29 0.5 13
AX28 30 0.5 13
AX29 31 0.5 13
AX30 32 0.5 13
AX31 33 0.5 13
AX32 34 0.5 13
AX33 35 0.5 13
AX34 36 0.5 13
AX35 37 0.5 13
AX36 38 0.5 13
AX37 39 0.5 13
AX38 40 0.5 13
AX39 41 0.5 13
AX40 42 0.5 13
AX41 43 0.5 13
AX42 44 0.5 13
AX43 45 0.5 13
AX44 46 0.5 13
AX45 47 0.5 13
AX46 48 0.5 13
AX47 49 0.5 13
AX48 50 0.5 13
AX49 51 0.5 13
AX50 52 0.5 13
AX51 53 0.5 13
AX52 54 0.5 13
AX53 55 0.5 13
AX54 56 0.5 13
AX55 57 0.5 13
AX56 58 0.5 13
AX57 59 0.5 13
AX58 60 0.5 13
AX59 61 0.5 13
AX60 62 0.5 13
AX61 63 0.5 13
AX62 64 0.5 13
AX63 65 0.5 13
AX64 66 0.5 13
AX65 67 0.5 13
AX66 68 0.5 13
AX67 69 0.5 13
AX68 70 0.5 13
AX69 71 0.5 13
AX70 72 0.5 13
AX71 73 0.5 13
AX72 74 0.5 13
AX73 75 0.5 13
AX74 76 0.5 13
AX75 77 0.5 13
AX76 78 0.5 13
AX77 79 0.5 13
AX78 80 0.5 13
AX79 81 0.5 13
AX80 82 0.5 13
AX81 83 0.5 13
AX82 84 0.5 13
AX83 85 0.5 13
AX84 86 0.5 13
AX85 87 0.5 13
AX86 88 0.5 13
AX87 89 0.5 13
AX88 90 0.5 13
AX89 91 0.5 13
AX90 92 0.5 13
AX91 93 0.5 13
AX92 94 0.5 13
AX93 95 0.5 13
AX94 96 0.5 13
AX95 97 0.5 13
AX96 98 0.5 13
AX97 99 0.5 13
AX98 100 0.5 13
B100 103 0.66 17
B101 104 0.66 17
B102 105 0.66 17
B103 106 0.66 17
B104 107 0.66 17
B105 108 0.66 17
B106 109 0.66 17
B107 110 0.66 17
B108 111 0.66 17
B109 112 0.66 17
B110 113 0.66 17
B111 114 0.66 17
B112 115 0.66 17
B113 116 0.66 17
B114 117 0.66 17
B115 118 0.66 17
B116 119 0.66 17
B117 120 0.66 17
B118 121 0.66 17
B119 122 0.66 17
B120 123 0.66 17
B122 125 0.66 17
B123 126 0.66 17
B124 127 0.66 17
B125 128 0.66 17
B126 129 0.66 17
B127 130 0.66 17
B128 131 0.66 17
B130 133 0.66 17
B131 134 0.66 17
B132 135 0.66 17
B133 136 0.66 17
B134 137 0.66 17
B135 138 0.66 17
B136 139 0.66 17
B137 140 0.66 17
B138 141 0.66 17
B139 142 0.66 17
B140 143 0.66 17
B141 144 0.66 17
B142 145 0.66 17
B143 146 0.66 17
B144 147 0.66 17
B145 148 0.66 17
B146 149 0.66 17
B147 150 0.66 17
B148 151 0.66 17
B149 152 0.66 17
B150 153 0.66 17
B151 154 0.66 17
B152 155 0.66 17
B153 156 0.66 17
B154 157 0.66 17
B156 159 0.66 17
B157 160 0.66 17
B158 161 0.66 17
B160 163 0.66 17
B161 164 0.66 17
B162 165 0.66 17
B164 167 0.66 17
B165 168 0.66 17
B166 169 0.66 17
B167 170 0.66 17
B168 171 0.66 17
B169 172 0.66 17
B170 173 0.66 17
B172 175 0.66 17
B173 176 0.66 17
B174 177 0.66 17
B175 178 0.66 17
B177 180 0.66 17
B178 181 0.66 17
B180 183 0.66 17
B182 185 0.66 17
B24 27 0.66 17
B25 28 0.66 17
B26 29 0.66 17
B27 30 0.66 17
B28 31 0.66 17
B29 32 0.66 17
B30 33 0.66 17
B31 34 0.66 17
B32 35 0.66 17
B33 36 0.66 17
B34 37 0.66 17
B35 38 0.66 17
B36 39 0.66 17
B37 40 0.66 17
B38 41 0.66 17
B39 42 0.66 17
B40 43 0.66 17
B41 44 0.66 17
B42 45 0.66 17
B43 46 0.66 17
B44 47 0.66 17
B45 48 0.66 17
B46 49 0.66 17
B47 50 0.66 17
B48 51 0.66 17
B49 52 0.66 17
B50 53 0.66 17
B51 54 0.66 17
B52 55 0.66 17
B53 56 0.66 17
B54 57 0.66 17
B55 58 0.66 17
B56 59 0.66 17
B57 60 0.66 17
B58 61 0.66 17
B59 62 0.66 17
B60 63 0.66 17
B61 64 0.66 17
B62 65 0.66 17
B63 66 0.66 17
B64 67 0.66 17
B65 68 0.66 17
B66 69 0.66 17
B67 70 0.66 17
B68 71 0.66 17
B69 72 0.66 17
B70 73 0.66 17
B71 74 0.66 17
B72 75 0.66 17
B73 76 0.66 17
B74 77 0.66 17
B75 78 0.66 17
B76 79 0.66 17
B77 80 0.66 17
B78 81 0.66 17
B79 82 0.66 17
B80 83 0.66 17
B81 84 0.66 17
B82 85 0.66 17
B83 86 0.66 17
B84 87 0.66 17
B85 88 0.66 17
B86 89 0.66 17
B87 90 0.66 17
B88 91 0.66 17
B89 92 0.66 17
B90 93 0.66 17
B91 94 0.66 17
B92 95 0.66 17
B93 96 0.66 17
B94 97 0.66 17
B95 98 0.66 17
B96 99 0.66 17
B97 100 0.66 17
B98 101 0.66 17
B99 102 0.66 17
SPA3070 121.52 0.52 13
SPA3082 121.99 0.52 13
SPA3150 124.67 0.52 13
SPA3182 125.93 0.52 13
SPA3282 129.86 0.52 13
SPA3350 132.54 0.52 13
SPA3482 137.74 0.52 13
SPA3550 140.41 0.52 13
SPA3750 148.29 0.52 13
SPA4000 158.13 0.52 13
SPA4250 167.97 0.52 13
SPA4500 177.82 0.52 13
SPZ3150 124.16 0.38 10
SPZ3350 132.03 0.38 10
SPZ3550 139.9 0.38 10
XPA1000 40.02 0.52 13
XPA1032 41.28 0.52 13
XPA1060 42.38 0.52 13
XPA1082 43.25 0.52 13
XPA1107 44.23 0.52 13
XPA1120 44.74 0.52 13
XPA1132 45.22 0.52 13
XPA1150 45.93 0.52 13
XPA1157 46.2 0.52 13
XPA1180 47.11 0.52 13
XPA1207 48.17 0.52 13
XPA1232 49.15 0.52 13
XPA1250 49.86 0.52 13
XPA1257 50.14 0.52 13
XPA1272 50.73 0.52 13
XPA1282 51.12 0.52 13
XPA1300 51.83 0.52 13
XPA1307 52.11 0.52 13
XPA1320 52.62 0.52 13
XPA1332 53.09 0.52 13
XPA1340 53.41 0.52 13
XPA1357 54.08 0.52 13
XPA1360 54.19 0.52 13
XPA1375 54.78 0.52 13
XPA1382 55.06 0.52 13
XPA1400 55.77 0.52 13
XPA1407 56.04 0.52 13
XPA1425 56.75 0.52 13
XPA1430 56.95 0.52 13
XPA1432 57.03 0.52 13
XPA1450 57.74 0.52 13
XPA1457 58.01 0.52 13
XPA1482 59 0.52 13
XPA1500 59.71 0.52 13
XPA1507 59.98 0.52 13
XPA1525 60.69 0.52 13
XPA1532 60.96 0.52 13
XPA1550 61.67 0.52 13
XPA1557 61.95 0.52 13
XPA1582 62.93 0.52 13
XPA1600 63.64 0.52 13
XPA1607 63.92 0.52 13
XPA1630 64.82 0.52 13
XPA1632 64.9 0.52 13
XPA1650 65.61 0.52 13
XPA1657 65.89 0.52 13
XPA1662 66.08 0.52 13
XPA1675 66.59 0.52 13
XPA1680 66.79 0.52 13
XPA1682 66.87 0.52 13
XPA1700 67.58 0.52 13
XPA1707 67.85 0.52 13
XPA1732 68.84 0.52 13
XPA1750 69.55 0.52 13
XPA1757 69.82 0.52 13
XPA1782 70.81 0.52 13
XPA1800 71.52 0.52 13
XPA1807 71.79 0.52 13
XPA1832 72.78 0.52 13
XPA1850 73.48 0.52 13
XPA1857 73.76 0.52 13
XPA1882 74.74 0.52 13
XPA1900 75.45 0.52 13
XPA1907 75.73 0.52 13
XPA1932 76.71 0.52 13
XPA1950 77.42 0.52 13
XPA1982 78.68 0.52 13
XPA2000 79.39 0.52 13
XPA2032 80.65 0.52 13
XPA2057 81.63 0.52 13
XPA2082 82.62 0.52 13
XPA2120 84.11 0.52 13
XPA2132 84.59 0.52 13
XPA2182 86.56 0.52 13
XPA2207 87.54 0.52 13
XPA2227 88.33 0.52 13
XPA2232 88.52 0.52 13
XPA2240 88.84 0.52 13
XPA2282 90.49 0.52 13
XPA2300 91.2 0.52 13
XPA2307 91.48 0.52 13
XPA2332 92.46 0.52 13
XPA2360 93.56 0.52 13
XPA2382 94.43 0.52 13
XPA2430 96.32 0.52 13
XPA2432 96.4 0.52 13
XPA2482 98.37 0.52 13
XPA2500 99.08 0.52 13
XPA2532 100.34 0.52 13
XPA2582 102.3 0.52 13
XPA2607 103.29 0.52 13
XPA2650 104.98 0.52 13
XPA2682 106.24 0.52 13
XPA2732 108.21 0.52 13
XPA2782 110.18 0.52 13
XPA2800 110.89 0.52 13
XPA2832 112.15 0.52 13
XPA2882 114.11 0.52 13
XPA2982 118.05 0.52 13
XPA3000 118.76 0.52 13
XPA630 25.45 0.52 13
XPA670 27.03 0.52 13
XPA730 29.39 0.52 13
XPA732 29.47 0.52 13
XPA750 30.18 0.52 13
XPA760 30.57 0.52 13
XPA762 30.65 0.52 13
XPA772 31.04 0.52 13
XPA782 31.44 0.52 13
XPA800 32.15 0.52 13
XPA832 33.41 0.52 13
XPA850 34.11 0.52 13
XPA900 36.08 0.52 13
XPA910 36.48 0.52 13
XPA922 36.95 0.52 13
XPA932 37.34 0.52 13
XPA950 38.05 0.52 13
XPA967 38.72 0.52 13
XPA982 39.31 0.52 13
XPZ1000 39.51 0.38 10
XPZ1010 39.9 0.38 10
XPZ1012 39.98 0.38 10
XPZ1024 40.45 0.38 10
XPZ1037 40.97 0.38 10
XPZ1047 41.36 0.38 10
XPZ1060 41.87 0.38 10
XPZ1077 42.54 0.38 10
XPZ1080 42.66 0.38 10
XPZ1087 42.94 0.38 10
XPZ1112 43.92 0.38 10
XPZ1120 44.23 0.38 10
XPZ1137 44.9 0.38 10
XPZ1140 45.02 0.38 10
XPZ1150 45.42 0.38 10
XPZ1162 45.89 0.38 10
XPZ1180 46.6 0.38 10
XPZ1187 46.87 0.38 10
XPZ1202 47.46 0.38 10
XPZ1210 47.72 0.38 10
XPZ1212 47.92 0.38 10
XPZ1227 48.45 0.38 10
XPZ1237 48.84 0.38 10
XPZ1250 49.35 0.38 10
XPZ1262 49.83 0.38 10
XPZ1270 50.14 0.38 10
XPZ1287 50.81 0.38 10
XPZ1312 51.79 0.38 10
XPZ1320 52.11 0.38 10
XPZ1337 52.78 0.38 10
XPZ1340 52.9 0.38 10
XPZ1362 53.76 0.38 10
XPZ1387 54.75 0.38 10
XPZ1400 55.26 0.38 10
XPZ1412 55.73 0.38 10
XPZ1420 56.05 0.38 10
XPZ1430 56.44 0.38 10
XPZ1437 56.71 0.38 10
XPZ1450 57.23 0.38 10
XPZ1462 57.7 0.38 10
XPZ1470 58.01 0.38 10
XPZ1487 58.68 0.38 10
XPZ1500 59.2 0.38 10
XPZ1512 59.67 0.38 10
XPZ1520 59.98 0.38 10
XPZ1527 60.26 0.38 10
XPZ1537 60.65 0.38 10
XPZ1560 61.56 0.38 10
XPZ1562 61.64 0.38 10
XPZ1587 62.62 0.38 10
XPZ1600 63.13 0.38 10
XPZ1612 63.6 0.38 10
XPZ1637 64.59 0.38 10
XPZ1650 64.59 0.38 10
XPZ1662 65.57 0.38 10
XPZ1687 66.56 0.38 10
XPZ1700 67.07 0.38 10
XPZ1712 67.54 0.38 10
XPZ1737 68.53 0.38 10
XPZ1750 69.04 0.38 10
XPZ1762 69.51 0.38 10
XPZ1787 70.49 0.38 10
XPZ1800 71.01 0.38 10
XPZ1812 71.48 0.38 10
XPZ1837 72.46 0.38 10
XPZ1850 72.97 0.38 10
XPZ1862 73.45 0.38 10
XPZ1887 74.43 0.38 10
XPZ1900 74.81 0.38 10
XPZ1937 76.4 0.38 10
XPZ1950 76.91 0.38 10
XPZ1962 77.38 0.38 10
XPZ1987 78.37 0.38 10
XPZ2000 78.88 0.38 10
XPZ2030 80.06 0.38 10
XPZ2037 80.34 0.38 10
XPZ2062 81.32 0.38 10
XPZ2087 82.31 0.38 10
XPZ2120 83.6 0.38 10
XPZ2137 84.27 0.38 10
XPZ2187 86.24 0.38 10
XPZ2240 88.33 0.38 10
XPZ2280 89.9 0.38 10
XPZ2287 90.18 0.38 10
XPZ2300 90.69 0.38 10
XPZ2360 93.05 0.38 10
XPZ2410 95.02 0.38 10
XPZ2437 96.08 0.38 10
XPZ2487 98.05 0.38 10
XPZ2500 98.57 0.38 10
XPZ2540 100.14 0.38 10
XPZ2650 104.47 0.38 10
XPZ2800 110.38 0.38 10
XPZ2840 111.95 0.38 10
XPZ3000 118.25 0.38 10
XPZ604 23.92 0.38 10
XPZ612 24.23 0.38 10
XPZ630 24.94 0.38 10
XPZ637 25.22 0.38 10
XPZ640 25.34 0.38 10
XPZ660 26.12 0.38 10
XPZ670 26.52 0.38 10
XPZ672 26.6 0.38 10
XPZ682 26.99 0.38 10
XPZ710 28.09 0.38 10
XPZ722 28.57 0.38 10
XPZ730 28.88 0.38 10
XPZ737 29.16 0.38 10
XPZ750 29.67 0.38 10
XPZ758 29.98 0.38 10
XPZ762 30.14 0.38 10
XPZ787 31.04 0.38 10
XPZ800 31.64 0.38 10
XPZ812 32.11 0.38 10
XPZ825 32.62 0.38 10
XPZ837 33.12 0.38 10
XPZ850 33.6 0.38 10
XPZ862 34.08 0.38 10
XPZ875 34.59 0.38 10
XPZ887 35.08 0.38 10
XPZ900 35.57 0.38 10
XPZ912 36.08 0.38 10
XPZ925 36.56 0.38 10
XPZ937 37.03 0.38 10
XPZ950 37.54 0.38 10
XPZ962 38.01 0.38 10
XPZ987 39 0.38 10




AIR COMPRESSOR BELTS FOR PISTON AND ROTARY SCREW COMPRESSORS.







WWW.HKAIRCOMPRESSORS.COM
CURTIS AIR COMPRESSOR BELTS






WWW.HKAIRCOMPRESSORS.COM
INGERSOLL RAND COMPRESSOR BELTS






WWW.HKAIRCOMPRESSORS.COM
QUINCY COMPRESSOR BELTS








WWW.HKAIRCOMPRESSORS.COM
ATLAS COPCO COMPRESSOR BELTS





IN THE DALLAS, FORT WORTH AREA: CALL....214-428-2868




WWW.HKAIRCOMPRESSORS.COM





























































































No comments:
