ROTARY SCREW COMPRESSORS





Smart & Sophisticated Nx Series 4-15kW
NX SERIES: 5HP - 350HP ROTARY SCREW COMPRESSORS

4-15kW FIXED SPEED (VARIABLE SPEED AVAILABLE IN 8-15KW)



ROTARY SCREW COMPRESSORS




THE BEST RATED ROTARY SCREW COMPRESSORS ON THE MARKET WITH THE BEST EXTENDED WARRANTY PROGRAM.  CURTIS…#1 CUSTOMER SATISFACTION.



INDUSTRIAL AIR COMPRESSORS







The Nx’s smooth, quite operation is perfect for a wide variety of applications ranging from auto body shops to light industrial.



WE SERVICE THE FOLLOWING ROTARY SCREW COMPRESSORS:

CURTIS ROTARY SCREW COMPRESSORS

CHAMPION ROTARY SCREW COMPRESSORS

INGERSOLL RAND ROTARY SCREW COMPRESSORS

JENNY

DAVEY ROTARY SCREW COMPRESSORS

ATLAS COPCO ROTARY SCREW COMPRESSORS

QUINCY ROTARY SCREW COMPRESSORS

SULLAIR ROTARY SCREW COMPRESSORS


#AIRCOMPRESSORSERVICE





Nx 4-15 kW Features
dBA SHIELD NOISE REDUCTION
Designed for quiet operation.
  • Integration of centrifugal blower and drive motors make for extremely smooth and quiet operation
  • Extra-thick sound insulation reduces noise
  • Can be installed in applications where a quiet setting is important
eCOOL® TECHNOLOGY
The ultimate in system protection and reliability.
  • Protects critical components from compressor-generated heat
  • Extends component life and reduces downtime
  • Compartmentalized air flow design and standard aftercooler




H&K AIR COMPRESSORS

214-428-2868






ROTARY SCREW COMPRESSOR SERVICE




ROTARY SCREW MAINTENANCE

ROTARY SCREW SERVICE

ROTARY SCREW REPAIR

AIR COMPRESSOR SERVICE




QUALITY COMPONENTS
Built to the highest levels of dependability and reliability.
  • Standard TEFC motor protects compressor from surrounding dirty air, increasing the efficiency and proloning the life of the motor.
  • Spin-on air/oil separator allows for quick maintenance and results in one-to-three PPM oil carryover. This translates into lower maek-oup oil costs and higher quality compressor air. This
    translates into lower make-up oil costs and higher quality compressed air.
SUPERIOR PACKAGE DESIGN
Designed for low cost of ownership and easy service.





AIR COMPRESSOR SERVICE



  • Space-saving design
  • Pulsation-free air
  • 100% continuous duty
  • Extended service intervals
  • More CFM per horsepower
  • Improved air quality
  • Energy efficiency at full load delivers more air for the mone integrated into a smaller footprint
  • Exclusive FS-Curtis airends utilize the latest rotor profile to maximize efficiency
OPTIONAL INTELLIGENT VARIABLE SPEED DRIVE  8-15kW
  • The VSD - time proven directly coupled design - offers faster response and greater operational efficiency
  • Variable operation slows airend speed, which lowers energy costs and reduces wear
  • With DemandSmart technology, the VSD enhances quality by stabilizing air pressure at 1 psi increments
  • Built-in DC Choke protects against harmonic disturbances and eliminates the need to source additional corrective devices




AIR COMPRESSOR REPAIR




NxGEN Warranty
FS-Curtis backs the Nx products with first in industry extended warranty. The major components such as electric motor, separator tank, air/oil cooler and VFD/controller are covered by a full non-prorated 5 year and our airends are covered for a full 10 year of peace of mind coverage.


AIR COMPRESSOR SERVICE





LOOKING FOR ROTARY SCREW COMPRESSOR PARTS?

ROTARY SCREW SEPARATORS

ROTARY SCREW OIL

ROTARY SCREW FILTERS

ROTARY SCREW TEMP. SENSORS

ROTARY SCREW PRESSURE SWITCHES

ROTARY SCREW MIN. PRESSURE VALVES

ROTARY SCREW BELTS

ROTARY SCREW HOSES

ROTARY SCREW MOTORS

ROTARY SCREW AIR ENDS

ROTARY SCREW CONTROL PANELS

ROTARY SCREW SENSORS





AIR COMPRESSOR SERVICE




CALL: 214-428-2868









Model HP VOLT  PSI CFM Part Number
NxB30 40 230 100 196 FNB30DXX3HXXX
NxB30 40 460 FNB30DXX4HXXX
NxB30 40 230 125 173 FNB30DXX3JXXX
NxB30 40 460 FNB30DXX4JXXX
NxB30 40 230 150 163 FNB30DXX3KXXX
NxB30 40 460 FNB30DXX4KXXX
NxB30 40 230 175 149 FNB30DXX3LXXX
NxB30 40 460 FNB30DXX4LXXX
NxB37 50 230 100 234 FNB37DXX3HXXX
NxB37 50 460 FNB37DXX4HXXX
NxB37 50 230 125 203 FNB37DXX3JXXX
NxB37 50 460 FNB37DXX4JXXX
NxB37 50 230 150 193 FNB37DXX3KXXX
NxB37 50 460 FNB37DXX4KXXX
NxB37 50 230 175 180 FNB37DXX3LXXX
NxB37 50 460 FNB37DXX4LXXX
NxB30 40 230 100 196 FNB30DXD3HXXX
NxB30 40 460 FNB30DXD4HXXX
NxB30 40 230 125 173 FNB30DXD3JXXX
NxB30 40 460 FNB30DXD4JXXX
NxB30 40 230 150 163 FNB30DXD3KXXX
NxB30 40 460 FNB30DXD4KXXX
NxB30 40 230 175 149 FNB30DXD3LXXX
NxB30 40 460 FNB30EXD4LXXX
NxB37 50 230 100 234 FNB37DXD3HXXX
NxB37 50 460 FNB37DXD4HXXX
NxB37 50 230 125 203 FNB37DXD3JXXX
NxB37 50 460 FNB37DXD4JXXX
NxB37 50 230 150 193 FNB37DXD3KXXX
NxB37 50 460 FNB37DXD4KXXX
NxB37 50 230 175 180 FNB37DXD3LXXX
NxB37 50 460 FNB37DXD4LXXX


AIR COMPRESSOR SERVICE




H&K AIR COMPRESSORS

214-428-2868





ROTARY SCREW COMPRESSOR OIL





MODEL HP VOLT PSI CFM PART NUMBER
NxV45 60 460 100 288.3-63.5 FNV45EXX4HXPC
NxV45 60 460 125 262.7-70.5 FNV45EXX4JXPC
NxV45 60 460 150 244.7-64.2 FNV45EXX4KXPC
NxV55 75 460 100 345.4-71.3 FNV55EXX4HXPC
NxV55 75 460 125 314.2-94.0 FNV55EXX4JXPC
NxV55 75 460 150 277.4-122.3 FNV55EXX4KXPC
NxV75 100 460 100 498.8-120.7 FNV75FXX4HXPC
NxV75 100 460 125 450.8-119.7 FNV75FXX4JXPC
NxV75 100 460 150 411.3-117.4 FNV75FXX4KXPC
NxV90 125 460 100 567.3-120.7 FNV90FXX4HXPC
NxV90 125 460 125 505.5-119.7 FNV90FXX4JXPC
NxV90 125 460 150 456.5-117.5 FNV90FXX4KXPC
NxV110 150 460 100 * FNV110GXX4HXPC
NxV110 150 460 125 * FNV110GXX4JXPC
NxV110 150 460 150 * FNV110GXX4KXPC
NxV160 200 460 115 * FNV160HXX4JXPC
NxV185 250 460 115 * FNV185HXX4JXPC
RS SERIES     15 460 100 69 FRB15FUXXA4H1XXXX
RS SERIES     15 460 125 59 FRB15FUXXA4J1XXXX
RS SERIES     15 460 150 51 FRB15FUXXA4K1XXXX
RS SERIES     15 460 175 45 FRB15FUXXA4L1XXXX
RS SERIES     20 460 100 92 FRB20FUXXA4H1XXXX
RS SERIES     20 460 125 81 FRB20FUXXA4J1XXXX
RS SERIES     20 460 150 76 FRB20FUXXA4K1XXXX
RS SERIES     20 460 175 65 FRB20FUXXA4L1XXXX
RS SERIES     25 460 100 111 FRB25FUXXA4H1XXXX
RS SERIES     25 460 125 104 FRB25FUXXA4J1XXXX
RS SERIES     25 460 150 92 FRB25FUXXA4K1XXXX
RS SERIES     25 460 175 84 FRB25FUXXA4L1XXXX
RS SERIES     30 460 100 135 FRB30FUXXA4H1XXXX
RS SERIES     30 460 125 129 FRB30FUXXA4J1XXXX
RS SERIES     30 460 150 115 FRB30FUXXA4K1XXXX
RS SERIES     30 460 175 102 FRB30FUXXA4L1XXXX
RS SERIES     40 460 100 189 FRB40FUXXA4H1XXXX
RS SERIES     40 460 125 173 FRB40FUXXA4J1XXXX
RS SERIES     40 460 150 150 FRB40FUXXA4K1XXXX
RS SERIES     40 460 175 140 FRB40FUXXA4L1XXXX
RS SERIES     50 460 100 220 FRB50FUXXA4H1XXXX
RS SERIES     50 460 125 200 FRB50FUXXA4J1XXXX
RS SERIES     50 460 150 186 FRB50FUXXA4K1XXXX
RS SERIES     50 460 175 170 FRB50FUXXA4L1XXXX
RS SERIES     15 460 100 69 FRB15FU8XA4H1XXXX
RS SERIES     15 460 125 59 FRB15FU8XA4J1XXXX
RS SERIES     15 460 150 51 FRB15FU8XA4K1XXXX
RS SERIES     15 460 175 45 FRB15FU8XA4L1XXXX
RS SERIES     20 460 100 92 FRB20FU1XA4H1XXXX
RS SERIES     20 460 125 81 FRB20FU1XA4J1XXXX
RS SERIES     20 460 150 76 FRB20FU1XA4K1XXXX
RS SERIES     20 460 175 65 FRB20FU1XA4L1XXXX
RS SERIES     25 460 100 111 FRB25FU1XA4H1XXXX
RS SERIES     25 460 125 104 FRB25FU1XA4J1XXXX
RS SERIES     25 460 150 92 FRB25FU1XA4K1XXXX
RS SERIES     25 460 175 84 FRB25FU1XA4L1XXXX
RS SERIES     30 460 100 135 FRB30FU1XA4H1XXXX
RS SERIES     30 460 125 129 FRB30FU1XA4J1XXXX
RS SERIES     30 460 150 115 FRB30FU1XA4K1XXXX
RS SERIES     30 460 175 102 FRB30FU1XA4L1XXXX
RS SERIES     40 460 100 189 FRB40FU2XA4H1XXXXX
RS SERIES     40 460 125 173 FRB40FU2XA4J1XXXXX
RS SERIES     40 460 150 150 FRB40FU2XA4K1XXXXX
RS SERIES     40 460 175 140 FRB40FU2XA4L1XXXXX








COMPRESSOR SERVICE




MODEL # HP Voltage PSI CFM PART #
NxD75 100 460 100 495 FND75FXX4HXPC
NxD75 100 575 FND75FXX8HXPC
NxD75 100 460 125 437 FND75FXX4JXPC
NxD75 100 575 FND75FXX8JXPC
NxD75 100 460 150 416 FND75FXX4KXPC
NxD75 100 575 FND75FXX8KXPC
NxD75 100 460 175 382 FND75FXX4LXPC
NxD75 100 575 FND75FXX8LXPC
NxD90 125 460 100 553 FND90FXX4HXPC
NxD90 125 575 FND90FXX8HXPC
NxD90 125 460 125 492 FND90FXX4JXPC
NxD90 125 575 FND90FXX8JXPC
NxD90 125 460 150 448 FND90FXX4KXPC
NxD90 125 575 FND90FXX8KXPC
NxD90 125 460 175 424 FND90FXX4LXPC
NxD90 125 575 FND90FXX8LXPC
NxD110 150 460 125 622 FND110GXX4JXPC
NxD160 200 460 125 938 FND160HXX4JXPC
NxD185 250 460 125 1029 FND185HXX4JXPC
NxHE90 125 460 125 632 FHE90GXX4JXPC
NxHE110 150 460 125 755 FHE110GXX4JXPC
NxHE132 175 460 125 904 FHE132GXX4JXPC
NxHE160 200 460 125 1119 FHE160HXX4JXPC
NxHE185 250 460 125 1267 FHE185HXX4JXPC
NxHE200 275 460 125 1373 FHE200IXX4JXPC
NxHE220 300 460 125 1507 FHE220IXX4JXPC
NxHE260 350 460 125 1748 FHE260IXX4JXPC
NxV08 10 460 100 45-17 FNV08B8X4HXPC
NxV08 10 460 125 42-17 FNV08B8X4JXPC
NxV08 10 460 150 33-17 FNV08B8X4KXPC
NxV08 10 460 175 25-16 FNV08B8X4LXPC
NxV11 15 460 100 63-17 FNV11B8X4HXPC
NxV11 15 460 125 58-17 FNV11B8X4JXPC
NxV11 15 460 150 50-16 FNV11B8X4KXPC
NxV11 15 460 175 44-16 FNV11B8X4LXPC
NxV15 20 460 100 82-17 FNV15B8X4HXPC
NxV15 20 460 125 77-17 FNV15B8X4JXPC
NxV15 20 460 150 72-17 FNV15B8X4KXPC
NxV15 20 460 175 60-16 FNV15B8X4LXPC
NxV08 10 460 100 45-17 FNV08BXX4HXPC
NxV08 10 460 125 42-17 FNV08BXX4JXPC
NxV08 10 460 150 33-17 FNV08BXX4KXPC
NxV08 10 460 175 25-16 FNV08BXX4LXPC
NxV11 15 460 100 63-17 FNV11BXX4HXPC
NxV11 15 460 125 58-17 FNV11BXX4JXPC
NxV11 15 460 150 50-16 FNV11BXX4KXPC
NxV11 15 460 175 44-16 FNV11BXX4LXPC
NxV15 20 460 100 82-17 FNV15BXX4HXPC
NxV15 20 460 125 77-17 FNV15BXX4JXPC
NxV15 20 460 150 72-17 FNV15BXX4KXPC
NxV15 20 460 175 60-16 FNV15BXX4LXPC
NxV18 25 460 100 112-33 FNV18C1X4HXPC
NxV18 25 460 125 102-33 FNV18C1X4JXPC
NxV18 25 460 150 91-44 FNV18C1X4KXPC
NxV18 25 460 175 83-40 FNV18C1X4LXPC
NxV22 30 460 100 129-34 FNV22C1X4HXPC
NxV22 30 460 125 118-33 FNV22C1X4JXPC
NxV22 30 460 150 112-32 FNV22C1X4KXPC
NxV22 30 460 175 105-40 FNV22C1X4LXPC
NxV18 25 460 100 112-33 FNV18CXX4HXPC
NxV18 25 460 125 102-33 FNV18CXX4JXPC
NxV18 25 460 150 91-44 FNV18CXX4KXPC
NxV18 25 460 175 83-40 FNV18CXX4LXPC
NxV22 30 460 100 129-34 FNV22CXX4HXPC
NxV22 30 460 125 118-33 FNV22CXX4JXPC
NxV22 30 460 150 112-32 FNV22CXX4KXPC
NxV22 30 460 175 105-40 FNV22CXX4LXPC
NxV30 40 460 100 183-52 FNV30DXX4HXPC
NxV30 40 460 125 169-51 FNV30DXX4JXPC
NxV30 40 460 150 153-50 FNV30DXX4KXPC
NxV30 40 460 175 135-48 FNV30DXX4LXPC
NxV37 50 460 100 227-52 FNV37DXX4HXPC
NxV37 50 460 125 210-51 FNV37DXX4JXPC
NxV37 50 460 150 189-50 FNV37DXX4KXPC
NxV37 50 460 175 168-48
FNV37DXX4LXPC





AIR COMPRESSOR SERVICE





ROTARY SCREW MAINTENANCE

ROTARY SCREW SERVICE

ROTARY SCREW REPAIR






AIR COMPRESSOR SERVICE





Model HORSEPOWER VOLT PSI CFM PART NUMBER
NxB18 25 230 100 114 FNB18C1X3HXXX
NxB18 25 460 FNB18C1X4HXXX
NxB18 25 230 125 100 FNB18C1X3JXXX
NxB18 25 460 FNB18C1X4JXXX
NxB18 25 230 150 92 FNB18C1X3KXXX
NxB18 25 460 FNB18C1X4KXXX
NxB18 25 230 175 84 FNB18C1X3LXXX
NxB18 25 460 FNB18C1X4LXXX
NxB22 30 230 100 134 FNB22C1X3HXXX
NxB22 30 460 FNB22C1X4HXXX
NxB22 30 230 125 116 FNB22C1X3JXXX
NxB22 30 460 FNB22C1X4JXXX
NxB22 30 230 150 109 FNB22C1X3KXXX
NxB22 30 460 FNB22C1X4KXXX
NxB22 30 230 175 95 FNB22C1X3LXXX
NxB22 30 460 FNB22C1X4LXXX
NxB18 25 230 100 114 FNB18CXX3HXXX
NxB18 25 460 FNB18CXX4HXXX
NxB18 25 230 125 100 FNB18CXX3JXXX
NxB18 25 460 FNB18CXX4JXXX
NxB18 25 230 150 92 FNB18CXX3KXXX
NxB18 25 460 FNB18CXX4KXXX
NxB18 25 230 175 84 FNB18CXX3LXXX
NxB18 25 460 FNB18CXX4LXXX
NxB22 30 230 100 134 FNB22CXX3HXXX
NxB22 30 460 FNB22CXX4HXXX
NxB22 30 230 125 116 FNB22CXX3JXXX
NxB22 30 460 FNB22CXX4JXXX
NxB22 30 230 150 109 FNB22CXX3KXXX
NxB22 30 460 FNB22CXX4KXXX
NxB22 30 230 175 95 FNB22CXX3LXXX
NxB22 30 460 FNB22CXX4LXXX
NxB30 40 230 100 196 FNB30DXX3HXXX
NxB30 40 460 FNB30DXX4HXXX
NxB30 40 230 125 173 FNB30DXX3JXXX
NxB30 40 460 FNB30DXX4JXXX
NxB30 40 230 150 163 FNB30DXX3KXXX
NxB30 40 460 FNB30DXX4KXXX
NxB30 40 230 175 149 FNB30DXX3LXXX
NxB30 40 460 FNB30DXX4LXXX
NxB37 50 230 100 234 FNB37DXX3HXXX
NxB37 50 460 FNB37DXX4HXXX
NxB37 50 230 125 203 FNB37DXX3JXXX
NxB37 50 460 FNB37DXX4JXXX
NxB37 50 230 150 193 FNB37DXX3KXXX
NxB37 50 460 FNB37DXX4KXXX
NxB37 50 230 175 180 FNB37DXX3LXXX
NxB37 50 460 FNB37DXX4LXXX
NxD45 60 230 FND45EXX3HXPC
NxD45 60 460 100 288 FND45EXX4HXPC
NxD45 60 575 FND45EXX8HXPC
NxD45 60 230 FND45EXX3JXPC
NxD45 60 460 125 263 FND45EXX4JXPC
NxD45 60 575 FND45EXX8JXPC
NxD45 60 230 FND45EXX3KXPC
NxD45 60 460 150 246 FND45EXX4KXPC
NxD45 60 575 FND45EXX8KXPC
NxD45 60 230 FND45EXX3LXPC
NxD45 60 460 175 223 FND45EXX4LXPC
NxD45 60 575 FND45EXX8LXPC
NxD55 75 230 FND55EXX3HXPC
NxD55 75 460 100 356 FND55EXX4HXPC
NxD55 75 575 FND55EXX8HXPC
NxD55 75 230 FND55EXX3JXPC
NxD55 75 460 125 324 FND55EXX4JXPC
NxD55 75 575 FND55EXX8JXPC
NxD55 75 230 FND55EXX3KXPC
NxD55 75 460 150 293 FND55EXX4KXPC
NxD55 75 575 FND55EXX8KXPC
NxD55 75 230 FND55EXX3LXPC
NxD55 75 460 175 270 FND55EXX4LXPC
NxD55 75 575 FND55EXX8LXPC





AIR COMPRESSOR SERVICE





BRAND Model HP VOLT  PSI CFM Part Number
CURTIS NxB08 10 230 FNB08BXX3HXXX
CURTIS NxB08 10 460 100 45 FNB08BXX4HXXX
CURTIS NxB08 10 230 FNB08BXX3JXXX
CURTIS NxB08 10 460 125 42 FNB08BXX4JXXX
CURTIS NxB08 10 230 FNB08BXX3KXXX
CURTIS NxB08 10 460 150 37 FNB08BXX4KXXX
CURTIS NxB08 10 230 FNB08BXX3LXXX
CURTIS NxB08 10 460 175 33 FNB08BXX4LXXX
CURTIS NxB11 15 230 FNB11BXX3HXXX
CURTIS NxB11 15 460 100 63 FNB11BXX4HXXX
CURTIS NxB11 15 230 FNB11BXX3JXXX
CURTIS NxB11 15 460 125 58 FNB11BXX4JXXX
CURTIS NxB11 15 230 FNB11BXX3KXXX
CURTIS NxB11 15 460 150 50 FNB11BXX4KXXX
CURTIS NxB11 15 230 FNB11BXX3LXXX
CURTIS NxB11 15 460 175 45 FNB11BXX4LXXX
CURTIS NxB15 20 230 FNB15BXX3HXXX
CURTIS NxB15 20 460 100 82 FNB15BXX4HXXX
CURTIS NxB15 20 230 FNB15BXX3JXXX
CURTIS NxB15 20 460 125 77 FNB15BXX4JXXX
CURTIS NxB15 20 230 FNB15BXX3KXXX
CURTIS NxB15 20 460 150 72 FNB15BXX4KXXX
CURTIS NxB15 20 230 FNB15BXX3LXXX
CURTIS NxB15 20 460 175 62 FNB15BXX4LXXX
CURTIS NxB08 10 230 FNB08BXD3HXXX
CURTIS NxB08 10 460 100 45 FNB08BXD4HXXX
CURTIS NxB08 10 230 FNB08BXD3JXXX
CURTIS NxB08 10 460 125 42 FNB08BXD4JXXX
CURTIS NxB08 10 230 FNB08BXD3KXXX
CURTIS NxB08 10 460 150 37 FNB08BXD4KXXX
CURTIS NxB08 10 230 FNB08BXD3LXXX
CURTIS NxB08 10 460 175 33 FNB08BXD4LXXX
CURTIS NxB11 15 230 FNB11BXD3HXXX
CURTIS NxB11 15 460 100 63 FNB11BXD4HXXX
CURTIS NxB11 15 230 FNB11BXD3JXXX
CURTIS NxB11 15 460 125 58 FNB11BXD4JXXX
CURTIS NxB11 15 230 FNB11BXD3KXXX
CURTIS NxB11 15 460 150 50 FNB11BXD4KXXX
CURTIS NxB11 15 230 FNB11BXD3LXXX
CURTIS NxB11 15 460 175 45 FNB11BXD4LXXX
CURTIS NxB15 20 230 FNB15BXD3HXXX
CURTIS NxB15 20 460 100 82 FNB15BXD4HXXX
CURTIS NxB15 20 230 FNB15BXD3JXXX
CURTIS NxB15 20 460 125 77 FNB15BXD4JXXX
CURTIS NxB15 20 230 FNB15BXD3KXXX
CURTIS NxB15 20 460 150 72 FNB15BXD4KXXX
CURTIS NxB15 20 230 FNB15BXD3LXXX
CURTIS NxB15 20 460 175 62 FNB15BXD4LXXX


ROTARY SCREW COMPRESSOR






Model HP OLT PSI CFM Part Number
NxB08 10 230 FNB08B8X3HXXX
NxB08 10 460 100 45 FNB08B8X4HXXX
NxB08 10 230 FNB08B8X3JXXX
NxB08 10 460 125 42 FNB08B8X4JXXX
NxB08 10 230 FNB08B8X3KXXX
NxB08 10 460 150 37 FNB08B8X4KXXX
NxB08 10 230 FNB08B8X3LXXX
NxB08 10 460 175 33 FNB08B8X4LXXX
NxB11 15 230 FNB11B8X3HXXX
NxB11 15 460 100 63 FNB11B8X4HXXX
NxB11 15 230 FNB11B8X3JXXX
NxB11 15 460 125 58 FNB11B8X4JXXX
NxB11 15 230 FNB11B8X3KXXX
NxB11 15 460 150 50 FNB11B8X4KXXX
NxB11 15 230 FNB11B8X3LXXX
NxB11 15 460 175 45 FNB11B8X4LXXX
NxB15 20 230 FNB15B8X3HXXX
NxB15 20 460 100 82 FNB15B8X4HXXX
NxB15 20 230 FNB15B8X3JXXX
NxB15 20 460 125 77 FNB15B8X4JXXX
NxB15 20 230 FNB15B8X3KXXX
NxB15 20 460 150 72 FNB15B8X4KXXX
NxB15 20 230 FNB15B8X3LXXX
NxB15 20 460 175 62 FNB15B8X4LXXX
NxB08 10 230 FNB08B8U3HXXX
NxB08 10 460 100 45 FNB08B8U4HXXX
NxB08 10 230 FNB08B8U3JXXX
NxB08 10 460 125 42 FNB08B8U4JXXX
NxB08 10 230 FNB08B8U3KXXX
NxB08 10 460 150 37 FNB08B8U4KXXX
NxB08 10 230 FNB08B8U3LXXX
NxB08 10 460 175 33 FNB08B8U4LXXX
NxB11 15 230 FNB11B8U3HXXX
NxB11 15 460 100 63 FNB11B8U4HXXX
NxB11 15 230 FNB11B8U3JXXX
NxB11 15 460 125 58 FNB11B8U4JXXX
NxB11 15 230 FNB11B8U3KXXX
NxB11 15 460 150 50 FNB11B8U4KXXX
NxB11 15 230 FNB11B8U3LXXX
NxB11 15 460 175 45 FNB11B8U4LXXX
NxB15 20 230 FNB15B8U3HXXX
NxB15 20 460 100 82 FNB15B8U4HXXX
NxB15 20 230 FNB15B8U3JXXX
NxB15 20 460 125 77 FNB15B8U4JXXX
NxB15 20 230 FNB15B8U3KXXX
NxB15 20 460 150 72 FNB15B8U4KXXX
NxB15 20 230 FNB15B8U3LXXX
NxB15 20 460 175 62
FNB15B8U4LXXX




AIR COMPRESSOR REPAIR



BRAND MODEL HP Voltage Pressure CFM PART #
CURTIS NxB04 5 230/1 FNB04AXX2HXXX
CURTIS NxB04 5 230/3 100 22 FNB04AXX3HXXX
CURTIS NxB04 5 460/3 FNB04AXX4HXXX
CURTIS NxB04 5 230/1 FNB04AXX2JXXX
CURTIS NxB04 5 230/3 125 20 FNB04AXX3JXXX
CURTIS NxB04 5 460/3 FNB04AXX4JXXX
CURTIS NxB04 5 230/1 FNB04AXX2KXXX
CURTIS NxB04 5 230/3 150 17 FNB04AXX3KXXX
CURTIS NxB04 5 460/3 FNB04AXX4KXXX
CURTIS NxB04 5 230/1 FNB04AXX2LXXX
CURTIS NxB04 5 230/3 175 15 FNB04AXX3LXXX
CURTIS NxB04 5 460/3 FNB04AXX4LXXX
CURTIS NxB06 7.5 230/1 FNB06AXX2HXXX
CURTIS NxB06 7.5 230/3 100 29 FNB06AXX3HXXX
CURTIS NxB06 7.5 460/3 FNB06AXX4HXXX
CURTIS NxB06 7.5 230/1 FNB06AXX2JXXX
CURTIS NxB06 7.5 230/3 125 27 FNB06AXX3JXXX
CURTIS NxB06 7.5 460/3 FNB06AXX4JXXX
CURTIS NxB06 7.5 230/1 FNB06AXX2KXXX
CURTIS NxB06 7.5 230/3 150 24 FNB06AXX3KXXX
CURTIS NxB06 7.5 460/3 FNB06AXX4KXXX
CURTIS NxB06 7.5 230/1 FNB06AXX2LXXX
CURTIS NxB06 7.5 230/3 175 22 FNB06AXX3LXXX
CURTIS NxB06 7.5 460/3 FNB06AXX4LXXX
CURTIS NxB04 5 230/1 FNB04AXD2HXXX
CURTIS NxB04 5 230/3 100 22 FNB04AXD3HXXX
CURTIS NxB04 5 460/3 FNB04AXD4HXXX
CURTIS NxB04 5 230/1 FNB04AXD2JXXX
CURTIS NxB04 5 230/3 125 20 FNB04AXD3JXXX
CURTIS NxB04 5 460/3 FNB04AXD4JXXX
CURTIS NxB04 5 230/1 FNB04AXD2KXXX
CURTIS NxB04 5 230/3 150 17 FNB04AXD3KXXX
CURTIS NxB04 5 460/3 FNB04AXD4KXXX
CURTIS NxB04 5 230/1 FNB04AXD2LXXX
CURTIS NxB04 5 230/3 175 15 FNB04AXD3LXXX
CURTIS NxB04 5 460/3 FNB04AXD4LXXX
CURTIS NxB06 7.5 230/1 FNB06AXD2HXXX
CURTIS NxB06 7.5 230/3 100 29 FNB06AXD3HXXX
CURTIS NxB06 7.5 460/3 FNB06AXD4HXXX
CURTIS NxB06 7.5 230/1 FNB06AXD2JXXX
CURTIS NxB06 7.5 230/3 125 27 FNB06AXD3JXXX
CURTIS NxB06 7.5 460/3 FNB06AXD4JXXX
CURTIS NxB06 7.5 230/1 FNB06AXD2KXXX
CURTIS NxB06 7.5 230/3 150 24 FNB06AXD3KXXX
CURTIS NxB06 7.5 460/3 FNB06AXD4KXXX
CURTIS NxB06 7.5 230/1 FNB06AXD2LXXX
CURTIS NxB06 7.5 230/3 175 22 FNB06AXD3LXXX
CURTIS NxB06 7.5 460/3 FNB06AXD4LXXX




H&K AIR COMPRESSORS

214-428-2868




ROTARY SCREW MAINTENANCE

ROTARY SCREW SERVICE

ROTARY SCREW REPAIR



AIR COMPRESSOR SERVICE



#ROTARYSCREW
#ROTARYCOMPRESSORS
#LARGECOMPRESSORS
#ENERGYEFFICIENT






WWW.HKAIRCOMPRESSORS.COM



Model HP Voltage Pressure CFM Part Number
NxB04 5 230/1 FNB04A6X2HXXX
NxB04 5 230/3 100 22 FNB04A6X3HXXX
NxB04 5 460/3 FNB04A6X4HXXX
NxB04 5 230/1 FNB04A6X2JXXX
NxB04 5 230/3 125 20 FNB04A6X3JXXX
NxB04 5 460/3 FNB04A6X4JXXX
NxB04 5 230/1 FNB04A6X2KXXX
NxB04 5 230/3 150 17 FNB04A6X3KXXX
NxB04 5 460/3 FNB04A6X4KXXX
NxB04 5 230/1 FNB04A6X2LXXX
NxB04 5 230/3 175 15 FNB04A6X3LXXX
NxB04 5 460/3 FNB04A6X4LXXX
NxB06 7.5 230/1 FNB06A6X2HXXX
NxB06 7.5 230/3 100 29 FNB06A6X3HXXX
NxB06 7.5 460/3 FNB06A6X4HXXX
NxB06 7.5 230/1 FNB06A6X2JXXX
NxB06 7.5 230/3 125 27 FNB06A6X3JXXX
NxB06 7.5 460/3 FNB06A6X4JXXX
NxB06 7.5 230/1 FNB06A6X2KXXX
NxB06 7.5 230/3 150 24 FNB06A6X3KXXX
NxB06 7.5 460/3 FNB06A6X4KXXX
NxB06 7.5 230/1 FNB06A6X2LXXX
NxB06 7.5 230/3 175 22 FNB06A6X3LXXX
NxB06 7.5 460/3 FNB06A6X4LXXX
NxB04 5 230/1 FNB04A6U2HXXX
NxB04 5 230/3 100 22 FNB04A6U3HXXX
NxB04 5 460/3 FNB04A6U4HXXX
NxB04 5 230/1 FNB04A6U2JXXX
NxB04 5 230/3 125 20 FNB04A6U3JXXX
NxB04 5 460/3 FNB04A6U4JXXX
NxB04 5 230/1 FNB04A6U2KXXX
NxB04 5 230/3 150 17 FNB04A6U3KXXX
NxB04 5 460/3 FNB04A6U4KXXX
NxB04 5 230/1 FNB04A6U2LXXX
NxB04 5 230/3 175 15 FNB04A6U3LXXX
NxB04 5 460/3 FNB04A6U4LXXX
NxB06 7.5 230/1 FNB06A6U2HXXX
NxB06 7.5 230/3 100 29 FNB06A6U3HXXX
NxB06 7.5 460/3 FNB06A6U4HXXX
NxB06 7.5 230/1 FNB06A6U2JXXX
NxB06 7.5 230/3 125 27 FNB06A6U3JXXX
NxB06 7.5 460/3 FNB06A6U4JXXX
NxB06 7.5 230/1 FNB06A6U2KXXX
NxB06 7.5 230/3 150 24 FNB06A6U3KXXX
NxB06 7.5 460/3 FNB06A6U4KXXX
NxB06 7.5 230/1 FNB06A6U2LXXX
NxB06 7.5 230/3 175 22 FNB06A6U3LXXX
NxB06 7.5 460/3 FNB06A6U4LXXX




AIR COMPRESSOR PARTS






AIR COMPRESSOR FILTERS











AIR COMPRESSOR











AIR COMPRESSOR MOTOR REPAIR





#FSCURTIS
#AIRCOMPRESSORSERVICE



ROTARY SCREW COMPRESSOR










AIR COMPRESSOR SERVICE






H&K AIR COMPRESSORS
214-428-2868





AIR COMPRESSOR SERVICE










AIR COMPRESSOR REPAIR









AIR COMPRESSOR TANKS






LOOKING FOR ROTARY SCREW COMPRESSOR PARTS?

ROTARY SCREW SEPARATORS

ROTARY SCREW OIL

QUINCY ROTARY SCREW OIL

ATLAS COPCO ROTARY SCREW OIL

CURTIS ROTARY SCREW OIL

INGERSOLL RAND ROTARY SCREW OIL

ROTARY SCREW FILTERS

ROTARY SCREW TEMP. SENSORS

ROTARY SCREW PRESSURE SWITCHES

ROTARY SCREW MIN. PRESSURE VALVES

ROTARY SCREW BELTS

ROTARY SCREW HOSES

ROTARY SCREW MOTORS

ROTARY SCREW AIR ENDS

ROTARY SCREW CONTROL PANELS

ROTARY SCREW SENSORS

AIR COMPRESSOR SERVICE





THE BEST RATED ROTARY SCREW COMPRESSORS ON THE MARKET WITH THE BEST EXTENDED WARRANTY PROGRAM.  CURTIS…#1 CUSTOMER SATISFACTION.

























contact us for sales and service at: WWW.HKAIRCOMPRESSORS.COM
ROTARY SCREW COMPRESSOR SERVICE






#AIRCOMPRESSORREPAIR






AIR COMPRESSOR REPAIR







LARGE INDUSTRIAL COMPRESSORS





AIR COMPRESSOR SERVICE







COMPRESSOR REPAIR







ROTARY SCREW SERVICE







AIR COMPRESSOR SERVICE







AIR COMPRESSOR OIL






AIR COMPRESSOR REPAIR








#AIRCOMPRESSORSERVICE







AIR COMPRESSOR SERVICE






AIR COMPRESSOR SERVICE









INDUSTRIAL AIR COMPRESSORS






Posted by at

No comments:

Post a Comment

Subscribe to: Post Comments (Atom)
