Curtis ML 15 series air compressor part numbers, ML 15 SERVICE PARTS



CURTIS ML 15 SERIES AIR COMPRESSOR PART NUMBERS AND DESCRIPTIONS





H&K PUMP




ML 15 SERIES FCA2321  LOW OIL GUARD ASSY
ML 15 SERIES FCA2342P  BELT GUARD AFTERCOOLER ASSY.
ML 15 SERIES FCAA2264  LOWER, BELT GUARD BRACKET
ML 15 SERIES FCAX1942  BELT GUARD STRAP
ML 15 SERIES FCCC1679  STUD MONTING 3/8-16 X 2" LG
ML 15 SERIES FCCC1681  PRESSURE SWITCH TREE
ML 15 SERIES FVSG839  STARTER, 15HP, 3/60/200V
ML 15 SERIES FVSG840  STARTER, 15HP, 3/60/230V
ML 15 SERIES FVSG841  STARTER, 15HP, 3/60/460V
ML 15 SERIES FMT153X4  MOTOR, 15HP. 3/60/230V
ML 15 SERIES FMT153X4  MOTOR, 15HP, 3/60/460V
ML 15 SERIES FOF269  TAKE-UP, MOTOR BOLT
ML 15 SERIES FOFA231  NUT-DISCHARGE TUBE- 1 1/8" FLARE
ML 15 SERIES FOFB213  MOTOR BOLT
ML 15 SERIES FOFD820  DISCHARGE TUBE, D97 TO AFTERCOOLER
ML 15 SERIES FOJA205A  MTG PLATE FOR WEG STARTER
ML 15 SERIES FOJA208A  MTG PLATE FOR WEG STARTER
ML 15 SERIES FRN60138  CONNECTOR 1" NPT X 1 y." NPT
ML 15 SERIES FPTP02AB  PLUG, sa HEAD STEEL y."
ML 15 SERIES FPTE06AB  ELBOW-BLACK 1" 90 DEGREE
ML 15 SERIES FPTE07AB  ELBOW-BLACK 1 y."" 90 DEGREE
ML 15 SERIES FPTS02AB  ELBOW-STREET-BLACK 90 DEG 1/4"
ML 15 SERIES FPTS06AB  ELBOW-STREET- BLACK 1"
ML 15 SERIES FVA1120  FILTER I SILENCER
ML 15 SERIES FVA1121  FILTER, INTAKE ELEMENT
ML 15 SERIES FPTB0302AB  BUSHING, REDUCING 3/8" X y." NPT
ML 15 SERIES FPTN0209AB  NIPPLE, PIPE 1/4" X 2" BLACK
ML 15 SERIES FPTN0609AB  NIPPLE-SHORT-BLACK 1"
ML 15 SERIES FPTN0717AB  NIPPLE 1 y." X 6" BLACK
ML 15 SERIES FVA14ACE  CONNECTION-COMPRESSION
ML 15 SERIES FVA14BCE  FITTING COMPRESSION 1/4" MPT
ML 15 SERIES FVA1502  FILTER, AIR LINE
ML 15 SERIES FVA302  PRESSURE GAUGE. AIR
ML 15 SERIES 2689510010 AIR COOLED AFTER COOLER
ML 15 SERIES FVAB721  CONNECTOR FLARE 1 y." NPT
ML 15 SERIES FVD319  V-BELT
ML 15 SERIES FVDB353  PULLEY











ML 15 SERIES FVH32C1  #10 FLAT WASHER
ML 15 SERIES FVH32F1  FLAT WASHER 1/4"
ML 15 SERIES FVH32P1  WASHER CUT Y:." ZINC PLATED
ML 15 SERIES FVH35B1  #8 LOCK WASHER (USE WITH 52 B)
ML 15 SERIES FVH35D  #10 LOCK WASHER (USE WITH 52 B)
ML 15 SERIES FVH35F1  LOCK WASHER 114"
ML 15 SERIES FMT159X4  MOTOR, 15HP, 3/60/200V
ML 15 SERIES FVS300  PRESSURE SWITCH
ML 15 SERIES FW223B  VALVE 3 WAY-SOLENOID Y:." 230/60 HZ
ML 15 SERIES FW223C  VALVE 3 WAY-SOLENOID Y:." 460/60 HZ
ML 15 SERIES FW223G  VALVE 3 WAY-SOLENOID Y:."
ML 15 SERIES FW404  SAFETY VALVE
ML 15 SERIES FW405  SAFETY VALVE y." NPT-CHROME
ML 15 SERIES FW514  DRAIN COCK
ML 15 SERIES FW554  VALVE, BALL
ML 15 SERIES FVH10PM1  BOLT CARRIAGE, Y:. -13 X Y:."
ML 15 SERIES FVH12FF1  HHCS 1/4-20 X 3/4" LG
ML 15 SERIES FVH12HF1  HHCS 5/16-18 X 3/4" LG
ML 15 SERIES FVH1536  NUT
ML 15 SERIES FVH1537  NUT, HEX SERRATED FLANGE GR2
ML 15 SERIES FVH1538  NUT
ML 15 SERIES FVH15H1  NUT-FINISHED CUT 5/16 -18"












CURTIS ML 15+ SERIES


ML 15+ SERIES FCA2342P  BELT GUARD AFTERCOOLER ASSY.
ML 15+ SERIES FCAA2264  LOWER. BELT GUARD BRACKET
ML 15+ SERIES FCAX1942  UPPER, BELT GUARD BRACKET
ML 15+ SERIES FCAX1942  BELT GUARD STRAP
ML 15+ SERIES FCCC1679  STUD MONTING 3/8-16 X 2" LG
ML 15+ SERIES FCCC1681  PRESSURE SWITCH TREE
ML 15+ SERIES FVSG839  STARTER, 15HP, 3/60/200V
ML 15+ SERIES FVSG841  STARTER, 15HP, 3/60/460V
ML 15+ SERIES FMT153X4  MOTOR, 15HP, 3/60/460V
ML 15+ SERIES FOF269  TAKE-UP, MOTOR BOLT
ML 15+ SERIES FOFB213  NUT, DISCHARGE TUBE
ML 15+ SERIES FOFB213  MOTOR BOLT
ML 15+ SERIES FOFD815  DISCHARGE TUBE, AFTERCOOLER TO
ML 15+ SERIES TANK
ML 15+ SERIES FOFD820  DISCHARGE TUBE, C89A TO
ML 15+ SERIES AFTERCOOLER (L.H)
ML 15+ SERIES FOFD820  DISCHARGE TUBE, D97 TO AFTERCOOLER
ML 15+ SERIES FOFD820F  DISCHARGE TUBE, C89A TO
ML 15+ SERIES AFTER COOLER (R.H)
ML 15+ SERIES FOJ218  MOUNTING PLATE FOR WEG STARTER
ML 15+ SERIES FOJA205A  MTG PLATE FOR WEG STARTER
ML 15+ SERIES FRN60138  CONNECTOR, FLARE
ML 15+ SERIES FRN60138  CONNECTOR 1" NPT X 1 14" NPT
ML 15+ SERIES FPTP02AB  PLUG, SQ HEAD STEEL 14"
ML 15+ SERIES FPTP04AB  PLUG- SQUARE HEAD-STEEL 1/2"
ML 15+ SERIES FPTE06AB  ELBOW-BLACK 1" 90 DEGREE
ML 15+ SERIES FPTE06AB  ELBOW-BLACK 1" 90 DEGREE
ML 15+ SERIES FPTE07AB  ELBOW-BLACK 1 14"" 90 DEGREE
ML 15+ SERIES FPTS02AB  ELBOW-·STREET-BLACK 90 DEG 1/4"
ML 15+ SERIES FPTS04AB  ELBOW-1/2" STREET-BLACK
ML 15+ SERIES FPTS06AB  ELBOW-STREET- BLACK 1"
ML 15+ SERIES FVAll14  FILTER, INTAKE ASSY
ML 15+ SERIES FVAl120  FILTER I SILENCER
ML 15+ SERIES FVAl121  FILTER, INTAKE ELEMENT
ML 15+ SERIES FPTB0302AB  BUSHING, REDUCING 3/8 X 1/4" NPT
ML 15+ SERIES FPTB0302AB  BUSHING, REDUCING 3/8" X 14" NPT












ML 15+ SERIES FPTN0609AB  NIPPLE-SHORT-BLACK 1"
ML 15+ SERIES FPTN0611AB  NIPPLE-BLACK 1" X 3"
ML 15+ SERIES FPTN0717AB  NIPPLE 1 14" X 6" BLACK
ML 15+ SERIES FVA14ACE  CONNECTION COMPRESSION STRAIGHT
ML 15+ SERIES FVA14ACE  CONNECTION-COMPRESSION
ML 15+ SERIES FVA14BCE  COMPRESSION FITTING 14"
ML 15+ SERIES FVA14BCE  FITTING COMPRESSION 1/4" MPT
ML 15+ SERIES FVA1502  FILTER, AIR LINE 1/8"
ML 15+ SERIES FVA1502  FILTER, AIR LINE
ML 15+ SERIES FVA15ACE  ELBOW: 90 DEG
ML 15+ SERIES FVA1602  TUBING, PRESSURE SWITCH TO CHECK
ML 15+ SERIES VALVE
ML 15+ SERIES FVA1602  TUBING, PRESSURE SWITCH TO SOLENOID
ML 15+ SERIES VALVE
ML 15+ SERIES FVA1602  TUBING, SOLENOID VALVE TO PUMP
ML 15+ SERIES FVA302  PRESSURE GAUGE, AIR
ML 15+ SERIES 2689510010 AIR COOLED AFTERCOOLER
ML 15+ SERIES FVA729  COMPRESSION TEE 14" X 14"
ML 15+ SERIES FVA748  COMPRESSION TEE 14" X 14" X 14"
ML 15+ SERIES FVA754  TEE, MALE 14" X 1/8"
ML 15+ SERIES FVAB721  CONNECTOR, FLARE 1 14" NPT Xl 1/8"
ML 15+ SERIES FVAB721  CONNECTOR FLARE 1 14" NPT
ML 15+ SERIES FVAC891  ELBOW STREET, 1 14" X 45 DEG.
ML 15+ SERIES FVD319  V-BELT
ML 15+ SERIES FVD341  V-BELT
ML 15+ SERIES FVDB353  MOTOR SHEAVE
ML 15+ SERIES FVDB353  PULLEY
ML 15+ SERIES FVF134C  ISOLATOR PADS 4X6Xl
ML 15+ SERIES FVFl34D  ISOLATOR PADS 6X6Xl
ML 15+ SERIES FVH10PMl  BOLT, 3/8-16 X 1 1/4"
ML 15+ SERIES FVH12FF1'  HHCS 1/4-20 X 3/4" LG
ML 15+ SERIES FVH12HFl  HHCS 5/16"X W LG
ML 15+ SERIES FVH12HFl  HHCS 5/16-18 X 3/4" LG
ML 15+ SERIES FVH12PNl  HHCS 1/2 -13-16 X 1 3/4" GRADE 5
ML 15+ SERIES FVH1536  NUT
ML 15+ SERIES FVH1537  NUT, HEX SERRATED FLANGE GR2
ML 15+ SERIES FVH1538  NUT, HEX SERRATED FLANGE GR2
ML 15+ SERIES FVH1538  NUT
